All Metal Hotend Kit for Creality CR-10s PRO / CR-10 Max

Original price $ 63.50 - Original price $ 63.50
Original price $ 63.50
$ 63.50
$ 63.50 - $ 63.50
Current price $ 63.50
SKU Part Number: M2591-04
Description

This is an All Metal Hotend Kit for CR-10s PRO / CR-10 Max Printers.
This is a drop in All Metal Conversion kit for the CR-10s PRO / CR-10 Max Printers. It requires absolutely zero modification to your printer to install. Our uniquely designed cooling block eliminates need for a thermal tube. By not having a separate thermal tube inside the cooling block, it allows for faster heat dissipation.
The thermal heat break is made from Grade 5 Titanium Alloy to provide excellent thermal isolation between the heater and the cooling block. Titanium is extremely strong material and offers almost 3x lower thermal conductivity than stainless steel, creating more defined melt zone.
CNC Machined and Assembled in USA

Fits
  • CR-10s Pro
  • CR-10s Pro V2
  • CR-10 Max
What's in the box
  • Aluminum Cooling Block
  • Grade 5 Titanium Heat Break
  • Aluminum Heater Block
  • Brass Plated Wear Resistant MK8 .4mm Nozzle
  • Silicone Sock
  • Hardware kit
Installation

Installation Instructions - Video

Extra Nozzles

Brass Plated MK8 Nozzles

A2 Hardened tool steel MK8 nozzles

M2 Hardened High Speed Steel Nozzle MK8 nozzles

Customer Reviews

Based on 19 reviews
84%
(16)
5%
(1)
0%
(0)
0%
(0)
11%
(2)
A
Adam Hocum
Excellent and easy to install

Easy to swap out and works perfectly

T
Tim Mace
too short

the hot end is much shorter than the factory. my blower housing hits the bed before the nozzle is even near it. i have tried many different blower housings and have the same result. the printer is completely stock and has no other modifications.

Hello Tim,
What is the part number on your box? I think you might have received the M2583-04 instead of M2591-04. If this is the case, please let us know.

Thank you

S
Sean T.
Good upgrade to all-metal

This hot-end works, and works well!
I've gotten my system up to 300 C with no issues. Can easily print PC+CF, Nylon, and ABS.
I also went for the direct drive upgrade and designed a proper fan shroud. https://www.thingiverse.com/thing:5117607
Alex at MicroSwiss offered fantastic support. I'm very happy.

A
Arco
NOt a review, but question (srry)

Hello, I miss the dimensions of this hotend. Please provide that too so I can test if it works on my Anet ET5 pro.

M
Marcus
Prints are now awsome

I purchased the Micro-Swiss Hot-End for my CR 10S pro V2. I am new to printing but parts where a little stringy and PLA was pretty brittle. ABS was the same way. I purchased the hot-end and had the thermocouple where it comes together just under the block. Nothing but temperature warnings. I re-mounted the thermocouple with the Phillips and no more issues. Prints are clean and amazing! PLA was a lot less brittle. I didn't change any of the temperatures and prints are simply perfect! I can also print PLA in ECO mode with success.
